| Model | MY-1200 | MY-1300 | MY-1500 | MY-1650 |
| Max. Paper Size (mm) | 1230X850mm | 1320X940mm | 1510x1120mm | 1670x1200mm |
| Min. Paper Size (mm) | 350x450mm | 350x450mm | 450x500mm | 500x550mm |
| Max. Die-cutting Size (mm) | 1210x830mm | 1300x920mm | 1490x1100mm | 1650x1180mm |
| The minimum size in mouth | 8mm | 8mm | 8mm | 8mm |
| Max. Die-cutting Pressure | 350N/cm2 | 350N/cm2 | 380N/cm2 | 400N/cm2 |
| Processable Paper - Cardboard | 200-2000g/m2 | 200-2000g/m2 | 200-2000g/m2 | 200-2000g/m2 |
| Processable Paper - Corrugated Paper | ≤8mm | ≤8mm | ≤8mm | ≤8mm |
| Max. Die-cutting Speed | 4600 sheets/h | 4600 sheets/h | 4600sheets/h | 4200sheets/h |
| Max. Feeding Pile Height | 1400mm(above the level) | 1400mm(above the level) | 1400mm(above the level) | 1400mm(above the level) |
| Max. Collecting Pile Height | 1200mm(above the level) | 1250mm(above the level) | 1250mm(above the level) | 1300mm(above the level) |
| Total Power | 17KW | 18KW | 18KW | 23KW |
| Weight | 15T | 16.5T | 19.5T | 23T |
| Dimensions | 6400×2298×2346mm | 6500×2300×2346mm | 6870×2398×2356mm | 7000×2980×2450mm |
