| Model | 2SJ-50 | 2SJ-55 | 2SJ-60 |
| Suitable Material | HDPE LDPE LLDPE | HDPE LDPE LLDPE | HDPE LDPE LLDPE |
| Film Width | 600-1200mm | 800-1500mm | 1000-1500mm |
| Film Thickness | 0.03-0.20mm | 0.03-0.20mm | 0.03-0.20mm |
| Max. Extrusion Output | 80kg/hr. | 120kg/hr. | 150kg/hr. |
| Screw Diameter | φ50×2 | φ55×2 | φ60×2 |
| Screw L/D Length | 28:1/30:1 | 28:1/30:1 | 28:1/30:1 |
| Screw Material | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala |
| Cylinder Material | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala |
| Cylinder Cooling | 370W×2 | 550W×2 | 550W×2 |
| Driving Motor | 15kw×2 | 18.5kw×2 | 22kw×2 |
| Temperature Control | 3 | 3 | 4 |
| Average Power Consume | 55kw | 68kw | 90kw |
| Die Size | φ220mm | φ250mm | φ350mm |
| Temperature Control | 3 | 3 | 4 |
| Air Ring | 1 | 1 | 1 |
| Air Blower | 3kw | 5.5kw | 7.5kw |
| Center Steady Stick | 1 | 1 | 1 |
| Roller Width | 1100mm | 1600mm | 2000mm |
| Effective Width | 1000mm | 1500mm | 1800mm |
| Height Adjustable | 800mm | 800mm | 800mm |
| Take-up Speed | 10-65m/min | 10-65m/min | 10-65m/min |
| Take-up Motor | 1.5kw | 1.5kw | 2.2kw |
| Type | Surface Friction | Surface Friction | Surface Friction |
| Winding Motor | 10N.m | 16N.m | 16N.m |
| Winding Speed | 10-65m/min | 10-65m/min | 10-65m/min |
| Power Supply | 380V,50HZ,3PHASE | 380V,50HZ,3PHASE | 380V,50HZ,3PHASE |
| Outline Dimension (L×W×H) | 6.5×5.5×5.5m | 7.5×5.8×7.5m | 7.8×6.4×8m |
