| Model | 3SJ-50 | 3SJ-55 | 3SJ-65 |
| Suitable Material | HDPE LDPE LLDPE | HDPE LDPE LLDPE | HDPE LDPE LLDPE |
| Film Width | 800-1200mm | 1000-1500mm | 1200-2000mm |
| Film Thickness | 0.028-0.20mm | 0.028-0.20mm | 0.03-0.20mm |
| Max. Extrusion Output | 120kg/hr. | 150kg/hr. | 200kg/hr. |
| Screw Diameter | φ50×3 | Aφ55 Bφ60 Cφ55 | Aφ60 Bφ65 Cφ60 |
| Screw L/D Length | 28:1/30:1 | 28:1/30:1 | 28:1/30:1 |
| Screw Material | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala |
| Cylinder Material | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala |
| Cylinder Cooling | 370W×2/3 | 370W×2/3 | 550W×3/3 |
| Driving Motor | 15kw×3 | A18.5+B22+C18.5 | A22+B30+C22 |
| Temperature Control | 3×3 | 3×3 | 3×3 |
| Average Power Consume | 80kw | 95kw | 120kw |
| Die Size | 280mm | 350mm | 500mm |
| Temperature Control | 4 | 4 | 4 |
| Air Ring | 1 | 1 | 1 |
| Air Blower | 7.5kw | 11kw | 15kw |
| Roller Width | 1600mm | 2100mm | 2600mm |
| Take-up Speed | 5-50m/min | 5-50m/min | 5-50m/min |
| Take-up Motor | 1.5kw | 2.2kw | 2.2kw |
| Type | Surface Friction | Surface Friction | Surface Friction |
| Winding Motor | 1.5kw | 2.2kw | 2.2kw |
| Winding Speed | 5-50m/min | 5-50m/min | 5-50m/min |
| Outline Dimension (L×W×H) | 9.5×4.5×7.5m | 10.5×5.0×9m | 11.5×5.5×10m |
